Ford FW-30

Ford FW-30 tractor photo
1977 - 1982   FW Series
Four-wheel Drive (4WD) tractor
Series next:Ford FW-40
Series back:Ford FW-20






Production:

Distributor:Ford
Manufacturer:Steiger
Factory:Fargo, North Dakota, USA
Original price (USD):$85,166


Ford FW-30 Engine:

   Cummins 14.8L 8-cyl diesel
full engine details ...


Capacity:

Fuel:225 gal [851.6 L]
Hydraulic system:25 gal [94.6 L]


3-Point Hitch:

Rear Type:III
Rear lift (at 24"/610mm):12500 lbs [5670 kg]


Power Take-off (PTO):

Rear PTO:independent*Optional. Hydrostatic-driven PTO
Rear RPM:540/1000


Dimensions & Tires:

Wheelbase:132.5 inches [336 cm]
Weight:31,310 lbs [14202 kg]
Front tire:18.4x38
Rear tire:18.4x38
full dimensions and tires ...


FW-30 Serial Numbers:


- Serial numbers unknown -



Ford FW-30 Power:

Engine (gross):265 hp [197.6 kW]
Drawbar (claimed):205 hp [152.9 kW]
PTO (claimed):57 hp [42.5 kW] (540 RPM)
 105 hp [78.3 kW] (1000 RPM)
Drawbar (tested):205.2 hp [153.0 kW]
power test details ...


Mechanical:

Chassis:4x4 articulated 4WD
Final drives:outboard planetary
Steering:articulated power
Brakes:hydraulic dry disc
Cab:Cab standard with air-conditioning.


Hydraulics:

Type:open center
Capacity:25 gal [94.6 L]
Pressure:2250 psi [155.1 bar]
Valves:4 or 5
Pump flow:30.1 gpm [113.9 lpm]
SCV flow:20 gpm [75.7 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:90


Battery:

Number:4
Cold-cranking amps:475*Each
Volts:12
