    Ford 9N

    Ford 9N tractor photo
    1939 - 1942   N Series
    Utility tractor
    Next model:Ford 2N






    Production:

    Manufacturer:Ford
    Factory:Dearborn, Michigan, USA
    Total built:99,002
    Original price (USD):$585 (1939)


    Ford 9N Engines:

       Ford 2.0L 4-cyl gasoline
       Ford 2.0L 4-cyl distillate
    full engine details ...


    Capacity:

    Fuel:10 gal [37.9 L]


    3-Point Hitch:

    Rear Type:I
    Rear lift:800 lbs [362 kg]


    Power Take-off (PTO):

    Rear PTO:transmission
    Rear RPMs:545 (1.125)


    Dimensions & Tires:

    Wheelbase:70 inches [177 cm]
    Weight:2140 to 3375 pounds
    Front tire:4.00-19
    Rear tire:8.00-32
    full dimensions and tires ...


    9N Serial Numbers:

    Location:On the engine block, left-hand side, just behind oil filter.
    photo of 9N serial number

    1939: 1
    1940: 10234
    1941: 45976
    1942: 89888

    how to read serial numbers...



    Links:

    N Tractor Club:


    Ford 9N Power:

    Drawbar (claimed):12.68 hp [9.5 kW]
    Belt (claimed):20.29 hp [15.1 kW]
    Plows:2 (14-inch)
    Drawbar (tested):16.31 hp [12.2 kW]
    Belt (tested):23.56 hp [17.6 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
    Steering:manual
    Brakes:differential mechanical shoe
    Cab:Open operator station


    Electrical:

    Ground:positive
    Charging system:generator
    Charging amps:16
    Charging volts:6


    Battery:

    Number:1
    Volts:6
    Amp-hours:85
