John Deere 5010 - transmission

John Deere 5010 tractor photo
1963 - 1965   New Generation Series
Standard-tread tractor
Next model:John Deere 5020
more John Deere 5010 specifications...






Transmission:

Transmission:Syncro-Range
Gears:8 forward and 3 reverse
Oil capacity:68 qts [64.4 L]
Oil type:
303 Special

Four shift stations, each with two forward gears and a reverse (except fourth station). Tractor must be stopped and clutch used to select shift station. Tractor can be shifted between gears in the station on the move while using the clutch.
Speeds:With 24.5-32 rear tires.
5010 Syncro-Range  speeds
