Kubota B20
| | 1990 - 1998 |
| Backhoe loader tractor |
|
| Production |
| Manufacturer | Kubota
|
| Type | Backhoe loader tractor
|
| Variants |
| B1750 | compact tractor
|
| Kubota B20 Power |
| Engine (gross) | 20 hp
14.9 kW
|
| Engine (net) | 17.5 hp
13.0 kW
|
| PTO (claimed) | 13.5 hp
10.1 kW
|
| Mechanical |
| Chassis | 4x4 MFWD 4WD
|
| Differential lock | mechanical rear
|
| Steering | power
|
| Brakes | dry disc
|
| Cab | Two-post ROPS. FOPS optional.
|
| Hydraulics |
| Type | open center
|
| Pressure | 2000 psi
137.9 bar
|
| Valves | 1
|
| Pump flow | 12.7 gpm
48.1 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control
|
| Rear lift (at ends) | 1279 lbs
580 kg
|
| Rear lift (at 24"/610mm) | 1014 lbs
459 kg
|
| Power Take-off (PTO) |
| Rear PTO | live
|
| Rear RPM | 540
|
| Engine RPM | 540@2534
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Battery volts | 12
|
| Page information |
| Last update | May 15, 2019
|
| Copyright | Copyright 2020 TractorData LLC
|
| Contact | Peter@TractorData.com
|
