Kubota B21


Kubota B21 backhoe photo
2001 - 2007
Backhoe loader tractor
Production
ManufacturerKubota
Backhoe loader tractor
Kubota B21 Engine
Kubota 1.0L 3-cyl diesel
Engine details ...
Kubota B21 Power
Engine (gross)21 hp
15.7 kW
Engine (net)19 hp
14.2 kW
PTO (claimed)13.5 hp
10.1 kW
Mechanical
Four-wheel drive
Differential lockmechanical rear
Power steering
Wet disc brakes
Four-post ROPS/FOPS.
Photos
No photos of the Kubota B21 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel6.3 gal
23.8 L
Hydraulic system7.3 gal
27.6 L
Hydraulics
Typeopen center
Capacity7.3 gal
27.6 L
Pump flow7.1 gpm
26.9 lpm
Total flow8.5 gpm
32.2 lpm
Steering flow1.3 gpm
4.9 lpm
Tractor hitch
Rear TypeI
Controlposition control
Rear lift (at 24"/610mm)1057 lbs
479 kg
Power Take-off (PTO)
Rear PTOlive
Rear RPM540
Dimensions & Tires
Wheelbase60.4 inches
153 cm
Weight3988 lbs
1808 kg
Front tire23x8.50-14
Rear tire12.4-16
Full dimensions and tires ...
Backhoe & Loader
Dig depth91.7 inches
232 cm
Dump angle45 inches
114 cm
Loader/Backhoe details ...
Electrical
Groundnegative
Battery volts12
References
B21 references literature
B21/L35 published in 1998, by Kubota
1999 Products published by Kubota
