John Deere 500



John Deere 500 tractor photo
1972 - 1974
Model year
Snowmobile
Series map:
400
500
600
28.0hp
36.0hp
36.0hp
Production
ManufacturerJohn Deere
Snowmobile
Built in Horicon, Wisconsin, USA
Original price was $1,340 in 1973
John Deere 500 Engine
36HP Canadian Curtiss-Wright 435cc 2-cyl gasoline
Fuel tank5.5 gal
20.8 L
Engine details ...
Mechanical
Tracked
Manual steering
Mechanical band brakes
Suspensionbogie wheel
Photos
No photos of the John Deere 500 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Track and Dimensions
Weight386 lbs
175 kg
Length103.4 inches
262 cm
Width35.5 inches
90 cm
Height44 inches
111 cm
Track width15.5 inches
39 cm
Electrical
Groundnegative
Battery volts12
References
500 references literature
Operator's Manual 400, 500 and 600 Snowmobiles (OM-M63829) published in 1972
Nothing Runs Like A Deere published in 1972, by John Deere
