Craftsman 917.25556


Craftsman 917.25556 tractor photo
1992
Lawn tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
Lawn tractor
Original price was $1,000 in 1992
Craftsman 917.25556 Engine
12HP Briggs & Stratton 459cc 1-cyl gasoline
Fuel tank1.25 gal
4.7 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the Craftsman 917.25556 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Mid PTO Typepulley
Dimensions & Tires
Front tire15x6.00-6
Rear tire18x8.5-8
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps3 (battery)
 5 (lights)
Battery volts12
References
917.25556 references literature
Owner's Manual Model Number 917.255560 (133089) published in 1991
