Craftsman 917.27624


No photo available
2006
GT 5000 Series
Garden tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
Garden tractor
Craftsman 917.27624 Engine
25HP Kohler 721cc 2-cyl gasoline
Fuel tank5 gal
18.9 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the Craftsman 917.27624 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Mid PTO Typepulley
Dimensions & Tires
Front tire16x6.5-8
Rear tire23x10.5-12
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps15
Battery CCA280
Battery volts12
Battery AH35
Battery GroupU1R
References
917.27624 references literature
Owner's Manual 917.276240 (193488) published in 2005*
*Publication contains known errors.
