Craftsman 944.60486


No photo available
2004
LT 1000 Series
Lawn tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
Lawn tractor
Original price was CAD 1,800 in 2004
Variants
60416gear
60486hydrostatic
Craftsman 944.60486 Engine
11.9KW Briggs & Stratton 499cc 1-cyl gasoline
Fuel tank1.25 gal
4.7 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the Craftsman 944.60486 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Mid PTO Typepulley
Dimensions & Tires
Front tire15x6.00-6
Rear tire18x9.50-8
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps3 (charging)
 5 (lights)
Battery CCA230
Battery volts12
Battery AH28
Battery GroupU1R
References
944.60486 references literature
Owner's Manual 944.604861 (190961) published in 2004
