Craftsman 944.60216


No photo available
2003
LT 1000 Series
Lawn tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
Lawn tractor
Original price was CAD 1,700 in 2003
Craftsman 944.60216 Engine
12.3KW Briggs & Stratton 499cc 1-cyl gasoline
Fuel tank1.25 gal
4.7 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the Craftsman 944.60216 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Mid PTO Typepulley
Dimensions & Tires
Front tire15x6.00-6
Rear tire18x9.50-8
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps3 (charging)
 5 (lights)
Battery CCA190
Battery volts12
Battery AH25
Battery GroupU1R
References
944.60216 references literature
Owner's Manual 944.602161 (183326) published in 2002
