Snapper 3317524BVE
|
|
| Production | |
| Manufacturer | Snapper (a part of Briggs & Stratton) |
| Riding lawn mower | |
| Built in McDonough, Georgia, USA | |
| Snapper 3317524BVE Engine | |
| 17.5HP Briggs & Stratton 499cc 1-cyl gasoline | |
| Fuel tank | 1.75 gal 6.6 L |
 Engine details ... | |
| Snapper 3317524BVE Transmission | |
| 5-speed friction disc | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Mechanical drum brakes | |
| Open operator station. |
| Photos | |
| No photos of the Snapper 3317524BVE are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | manual |
| Mid PTO Type | pulley |
| Dimensions & Tires | |
| Wheelbase | 46 inches 116 cm |
| Weight | 365 lbs 165 kg |
| Front tire | 11x4.00-4 |
| Rear tire | 16x6.50-8 |
 Full dimensions and tires ... | |
| Snapper 3317524BVE attachments | |
| 33" mid-mount mower deck | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Operator's Manual Series 24 Rear Engine Riders (7104742) published in 2014 | |
| Lets Ride published in 2011, by Snapper | |
| Lawn and Garden Products published in 2012, by Snapper |
