Craftsman 917.25432 YT 16


Craftsman 917.25432 YT 16 tractor photo
1988
Lawn tractor
Roper built
Production
DistributorCraftsman (a part of Sears)
ManufacturerRoper
Lawn tractor
Craftsman 917.25432 Engine
16HP Briggs & Stratton 655cc 2-cyl gasoline
Fuel tank3.5 gal
13.2 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Mechanical disc brakes
Open operator station.
Photos
No photos of the Craftsman 917.25432 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Mid PTO Typepulley
Dimensions & Tires
Weight523 lbs
237 kg
Front tire15x6.0
Rear tire20x10
Full dimensions and tires ...
Craftsman 917.25432 attachments
44" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Battery volts12
References
917.25432 YT 16 references literature
Craftsman Tractors and Rear Engine Riders published in 1988, by Sears
