Lawn Chief 36536
|
|
| Production | |
| Distributor | Lawn Chief |
| Manufacturer | Murray |
| Lawn tractor | |
| Also sold as the 2-1136VD. | |
| Lawn Chief 36536 Engine | |
| 11HP Briggs & Stratton 399cc 1-cyl gasoline | |
| Fuel tank | 2 gal 7.6 L |
 Engine details ... | |
| Lawn Chief 36536 Transmission | |
| 12-speed variator | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Disc brakes | |
| Open operator station. |
| Photos | |
| No photos of the Lawn Chief 36536 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Dimensions & Tires | |
| Weight | 442 lbs 200 kg |
| Front tire | 15x6 |
| Rear tire | 18x9.50 |
 Full dimensions and tires ... | |
| Lawn Chief 36536 attachments | |
| 36" mid-mount mower deck | |
| snowblower | |
| blade | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| Battery AH | 25 |
| References | |
 | |
| Tractors and Rear Engine Riders published in 1985, by Lawn Chief |
