Sears Tri-Cut
|
|
| Production | |
| Distributor | Sears |
| Manufacturer | David Bradley |
| Riding lawn mower | |
| Built in Bradley, Illinois, USA | |
| Original price | $470 (1958 6hp 47-inch ) |
| $770 (1959 7hp 58-inch ) | |
| Sears Tri-Cut Engines | |
| 5.6HP Wisconsin 1-cyl gasoline | |
| 5.75HP Briggs & Stratton 1-cyl gasoline | |
| 7HP Briggs & Stratton 304cc 1-cyl gasoline | |
| Fuel tank | 1 gal (47) 3.8 L |
| 1.5 gal (58) 5.7 L | |
 Engine details ... | |
| Sears Tri-Cut Transmissions | |
| 2-speed | |
| 1-speed | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Open operator station. |
| Photos | |
| No photos of the Sears Tri-Cut are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | manual |
| Dimensions & Tires | |
| Wheelbase | 38 inches 96 cm |
| Weight | 475 lbs 215 kg |
| Front tire | 3.25-10.25 |
| Rear tire | 4.80-7 |
 Full dimensions and tires ... | |
| Sears Tri-Cut attachments | |
| 47" mid-mount mower deck | |
| 58" mid-mount mower deck | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Service - David Bradley (Div. 32 No. 9) published in 1959 |
