AGCO 517H
|
|
Note: the AGCO model 517H is the same as the Simplicity Regent 17H. The following data is from the Regent 17H listing. |
| Production | |
| Distributor | AGCO |
| Manufacturer | Simplicity |
| Lawn tractor | |
| Variants | |
| Regent 17H | similar Simplicity model |
| 2517H | similar Massey Ferguson model |
| AGCO 517H Engine | |
| 17HP Vanguard 501cc 1-cyl gasoline | |
| Fuel tank | 2 gal 7.6 L |
 Engine details ... | |
| AGCO 517H Transmission | |
| hydrostatic | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Open operator station. |
| Photos | |
| No photos of the AGCO 517H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | electric |
| Mid PTO Type | pulley |
| Dimensions & Tires | |
| Wheelbase | 50 inches 127 cm |
| Weight | 445 lbs 201 kg |
| Front tire | 15x6.5-6 |
| Rear tire | 20x8.0-8 |
 Full dimensions and tires ... | |
| AGCO 517H attachments | |
| 40" mid-mount mower deck | |
| snowblower | |
| blade | |
 Attachment details ... |
| Electrical | |
| Charging amps | 16 |
| Battery volts | 12 |
| References | |
 | |
| Lawn and Garden Equipment published in 2000, by AGCO |
