Snapper ZF2301GKU
|
|
| Production | |
| Manufacturer | Snapper |
| Front-mount mower | |
| Snapper ZF2301GKU Engine | |
| 23HP Kubota 719cc 3-cyl gasoline | |
| Fuel tank | 6 gal 22.7 L |
 Engine details ... | |
| Mechanical | |
| Two-wheel drive | |
| Power steering | |
| Disc brakes | |
| Open operator station. |
| Photos | |
| No photos of the Snapper ZF2301GKU are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | electric |
| Dimensions & Tires | |
| Wheelbase | 39 inches 99 cm |
| Weight | 755 lbs 342 kg |
| Front tire | 21x11.00-8 |
| Rear tire | 13x5.00-6 |
 Full dimensions and tires ... | |
| Snapper ZF2301GKU attachments | |
| 52" mid-mount mower deck | |
| 61" mid-mount mower deck | |
| 73" mid-mount mower deck | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging amps | 12.5 |
| Battery CCA | 450 |
| Battery volts | 12 |
| References | |
 | |
| Commercial Product Catalog published in 2002, by Snapper |
