Snapper MZM2300KH
|
|
| Production | |
| Manufacturer | Snapper |
| Zero-turn mower | |
| Snapper MZM2300KH Engine | |
| 23HP Kohler 671cc 2-cyl gasoline | |
| Fuel tank | 6 gal 22.7 L |
 Engine details ... | |
| Mechanical | |
| Two-wheel drive | |
| Power steering | |
| Disc brakes | |
| Open operator station. |
| Photos | |
| No photos of the Snapper MZM2300KH are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | electric |
| Dimensions & Tires | |
| Wheelbase | 48 inches 121 cm |
| Weight | 746 lbs 338 kg |
| Front tire | 13x5.00-6 |
| Rear tire | 21x11.00-8 |
 Full dimensions and tires ... | |
| Snapper MZM2300KH attachments | |
| 52" mid-mount mower deck | |
| 61" mid-mount mower deck | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging amps | 15 |
| Battery CCA | 380 |
| Battery volts | 12 |
| References | |
 | |
| Commercial Product Catalog published in 2002, by Snapper |
