AGCO 1606H
|
|
Note: the AGCO model 1606H is the same as the Simplicity Broadmoor 16H. The following data is from the Broadmoor 16H listing. |
| Production | |
| Distributor | AGCO |
| Manufacturer | Simplicity |
| Lawn tractor | |
| AGCO 1606H Engine | |
| 16HP Kohler 458cc 1-cyl gasoline | |
| Fuel tank | 4 gal 15.1 L |
 Engine details ... | |
| AGCO 1606H Transmission | |
| hydrostatic | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering |
| Photos | |
| No photos of the AGCO 1606H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | electric |
| Dimensions & Tires | |
| Wheelbase | 52 inches 132 cm |
| Weight | 690 lbs 312 kg |
| Front tire | 15x6.0-6 |
| Rear tire | 20x10-10 |
 Full dimensions and tires ... | |
| AGCO 1606H attachments | |
| 44" mid-mount mower deck | |
 Attachment details ... |
| References | |
 | |
| Lawn & Garden Equipment published in 2004, by AGCO |
