Craftsman 917.25933
| 1997 |
Lawn tractor | AYP built |
|
Series map:
917.25933
15.5hp
Production |
Distributor | Craftsman (a part of Sears)
|
Manufacturer | AYP
|
Lawn tractor |
Original price was $1,099 in 1997 |
Mechanical |
Two-wheel drive |
Manual steering |
Open operator station. |
Photos |
No photos of the Craftsman 917.25933 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Power Take-off (PTO) |
Mid PTO | independent
|
Clutch | manual
|
Electrical |
Ground | negative
|
Charging amps | 3 (battery)
|
  | 5 (lights)
|
Battery CCA | 190
|
Battery volts | 12
|
Battery AH | 25
|
Battery Group | U1R
|
References |
 |
Owner's Manual 917.259330 (156583) published in 1996 |
