AGCO 1620H
|
|
| Production | |
| Distributor | AGCO |
| Manufacturer | Simplicity |
| Lawn tractor | |
| Variants | |
| Broadmoor 20/44 | similar Simplicity model |
| 2620H | similar Massey Ferguson model |
| AGCO 1620H Engine | |
| 20HP Vanguard 568cc 2-cyl gasoline | |
| Fuel tank | 4 gal 15.1 L |
 Engine details ... | |
| AGCO 1620H Transmission | |
| hydrostatic | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Disc brakes | |
| Open operator station with 15-inch adjustable seat. |
| Photos | |
| No photos of the AGCO 1620H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | electric |
| Dimensions & Tires | |
| Wheelbase | 53 inches 134 cm |
| Weight | 470 lbs 213 kg |
| Front tire | 15x6.0-6 |
| Rear tire | 22x10.0-10 |
 Full dimensions and tires ... | |
| AGCO 1620H attachments | |
| 44" mid-mount mower deck | |
| snowblower | |
| blade | |
 Attachment details ... |
| Electrical | |
| Charging amps | 16 |
| Battery CCA | 230 |
| Battery volts | 12 |
| References | |
 | |
| Lawn and Garden Equipment published in 2009, by AGCO | |
| Operator's Manual Broadmoor / 300 / 1600 / 2600 Series (1732286) published in 2008 |
