Jacobsen GT12H 34002
|
|
| Production | |
| Manufacturer | Jacobsen |
| Garden tractor | |
| Jacobsen GT12H Engine | |
| 12HP Kohler 476cc 1-cyl gasoline | |
| Fuel tank | 3 gal 11.4 L |
 Engine details ... | |
| Jacobsen GT12H Transmission | |
| hydrostatic | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Mechanical band brakes | |
| Open operator station. |
| Photos | |
| No photos of the Jacobsen GT12H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | 0 OptOptional |
| Type | sleeve hitch OptOptional |
| Power Take-off (PTO) | |
| Rear PTO | independent OptOptional |
| Front PTO | independent |
| Clutch | electric |
| Dimensions & Tires | |
| Wheelbase | 46 inches 116 cm |
| Weight | 800 lbs 362 kg |
| Front tire | 16x6.50-8 |
| Rear tire | 23x8.50-12 |
 Full dimensions and tires ... | |
| Jacobsen GT12H attachments | |
| 42" mid-mount mower deck | |
| snowblower | |
| blade | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging amps | 15 |
| Battery volts | 12 |
| Battery AH | 22 |
| References | |
 | |
| Operator's Manual Hydro Tractors GT 12H, GT 14H, GT 16H (JA-99021-0) | |
| Consumer Products Catalog published in 1984, by Jacobsen |
