Woods FE21B
|
|
| Production | |
| Manufacturer | Woods |
| Front-mount mower | |
| Woods FE21B Engine | |
| 21HP Vanguard 2-cyl gasoline | |
| Fuel tank | 6 gal 22.7 L |
 Engine details ... | |
| Woods FE21B Transmission | |
| hydrostatic | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Power steering | |
| Open operator station. |
| Photos | |
| No photos of the Woods FE21B are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Dimensions & Tires | |
| Wheelbase | 51 inches 129 cm |
| Weight | 1080 lbs 489 kg |
| Front tire | 23x11-10 |
| Rear tire | 13x5.0-6 |
 Full dimensions and tires ... | |
| Woods FE21B attachments | |
| 52" front-mount mower deck | |
| 61" front-mount mower deck | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Mow'n Machine FZ and FE Series published in 2007, by Woods |
