Murray 39003
|
|
| Production | |
| Manufacturer | Murray |
| Garden tractor | |
| Murray 39003 Engine | |
| 16HP Briggs & Stratton 655cc 2-cyl gasoline | |
| Fuel tank | 3 gal 11.4 L |
 Engine details ... | |
| Murray 39003 Transmission | |
| 4-speed gear | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Disc brakes | |
| Open operator station. |
| Photos | |
| No photos of the Murray 39003 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Type | sleeve hitch OptOptional |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | manual |
| Dimensions & Tires | |
| Weight | 658 lbs 298 kg |
| Front tire | 16x6.50 |
| Rear tire | 23x8.50 |
 Full dimensions and tires ... | |
| Murray 39003 attachments | |
| 42" mid-mount mower deck | |
| snowblower | |
| blade | |
 Attachment details ... |
| 39003 Serial Numbers | |
| 1982 | 82-39003 (model code) |
| 1983 | 83-39003 (model code) |
| 1984 | 84-39003 (model code) |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| Murray Mowers for 1982 |
