Murray 3697


Murray 3697 tractor photo
1974 - 1980
Lawn tractor
Production
ManufacturerMurray
Lawn tractor
Built in Lawrenceburg, Tennessee, USA
The Murray 5-3697 was also sold as the Sears model 502.25801.
Murray 3697 Engine
10HP Briggs & Stratton 1-cyl gasoline
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Disc brakes
Open operator station.
Photos
No photos of the Murray 3697 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Dimensions & Tires
Weight507 lbs
229 kg
Front tire15x6.00
Rear tire18x9.50
Full dimensions and tires ...
Murray 3697 attachments
36" mid-mount mower deck
snowblower
blade
Attachment details ...
3697 Serial Numbers
19744-3697
19755-3697
19766-3697
19777-3697
19788-3697
19799-3697
19800-3697

FAQ: How to read a serial number table.
Electrical
Groundnegative
Battery volts12
References
3697 references literature
Murray Mowers 1974
1976 Murray
Mowers and Tiller for 77 published in 1977, by Murray
The 1979 Murray Mowers
The 1980 Murray Mowers
3697 manuals literature
Murray Parts Microfiche published in 1976
Murray Parts Microfiche published in 1977
Murray Parts Microfiche published in 1978
Murray Parts Microfiche published in 1979
