Craftsman 536.8145

Craftsman 536.8145 lawn tractor photo
1956 - 1960
Riding lawn mower
Western Tool built
DistributorCraftsman (a part of Sears)
ManufacturerWestern Tool
Riding lawn mower
Built in Des Moines, Iowa, USA
Original price was $300 in 1956
Information on this riding mower is limited. A two-cycle engine was used until 1958. Electric start and a new body appeared in 1959.
Craftsman 536.8145 Engine
4HP Power Products 131cc 1-cyl gasoline
Engine details ...
Two-wheel drive
Manual steering
Open operator station.
No photos of the Craftsman 536.8145 are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Dimensions & Tires
Weight264 lbs
119 kg
Front tire10-2.50
Rear tire12-3.00
Full dimensions and tires ...
536.8145 Serial Numbers
1956536.81450 (model code)
1957536.81451 (model code)
1958536.81453 (model code)
1959536.81456 (model code)
1960536.81456 (model code)

FAQ: How to read a serial number table.
536.8145 references literature
Service - DCraftsman Riding Mowers and Engines (Div. 9 No. 12) published in 1959
