Massey Ferguson 2724H
|
|
| Production | |
| Distributor | Massey Ferguson |
| Manufacturer | Simplicity |
| Garden tractor | |
| Variants | |
| Conquest 24/52 | similar Simplicity model |
| Massey Ferguson 2724H Engine | |
| 24HP Briggs & Stratton 724cc 2-cyl gasoline | |
| Fuel tank | 3.6 gal 13.6 L |
 Engine details ... | |
| Mechanical | |
| Two-wheel drive | |
| Steering | manual |
| Steering | power OptOptional |
| Open operator station with 18-inch adjustable seat. | |
| Photos | |
| No photos of the Massey Ferguson 2724H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | electric |
| Dimensions & Tires | |
| Wheelbase | 53.1 inches 134 cm |
| Weight | 680 lbs 308 kg |
| Front tire | 16x6.5-8 |
| Rear tire | 23x10.5-12 |
 Full dimensions and tires ... | |
| Massey Ferguson 2724H attachments | |
| 52" mid-mount mower deck | |
| blade | |
 Attachment details ... |
| 2724H Serial Numbers | |
| Location: | Serial number decal on the right side of the tractor frame, above the front axle. |
| Electrical | |
| Ground | negative |
| Charging amps | 16 |
| Battery CCA | 230 |
| Battery volts | 12 |
| References | |
 | |
| Lawn & Garden Equipment published in 2011, by Massey Ferguson |
