Gravely 1130
|
|
| Production | |
| Manufacturer | Gravely |
| Riding lawn mower | |
| Gravely 1130 Engine | |
| 11HP Briggs & Stratton 399cc 1-cyl gasoline | |
| Fuel tank | 0.75 gal 2.8 L |
 Engine details ... | |
| Gravely 1130 Transmission | |
| 3-speed gear | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Disc brakes | |
| Open operator station. |
| Photos | |
| No photos of the Gravely 1130 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Dimensions & Tires | |
| Wheelbase | 44 inches 111 cm |
| Weight | 335 lbs 151 kg |
| Front tire | 4.10x3.50-4 |
| Rear tire | 16x6.50-8 |
 Full dimensions and tires ... | |
| Gravely 1130 attachments | |
| 30" mid-mount mower deck | |
| blade | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Operator's Manual Riding Mowers (32188) published in 1979 |
