Craftsman 502.25565
|
|
| Production | |
| Distributor | Craftsman (a part of Sears) |
| Manufacturer | Murray |
| Riding lawn mower | |
| Original price was $1,400 in 1985 | |
| Craftsman 502.25565 Engine | |
| 11HP 1-cyl gasoline | |
| Fuel tank | 0.75 gal 2.8 L |
 Engine details ... | |
| Craftsman 502.25565 Transmission | |
| 8-speed friction disc | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Open operator station. |
| Photos | |
| No photos of the Craftsman 502.25565 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Dimensions & Tires | |
| Weight | 320 lbs 145 kg |
| Front tire | 11x4.0 |
| Rear tire | 16x6.5 |
 Full dimensions and tires ... | |
| Craftsman 502.25565 attachments | |
| 30" mid-mount mower deck | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Craftsman Tractors and Rear Engine Riders published in 1985, by Sears |
