Craftsman 917.27031


Craftsman 917.27031 lawn tractor photo
1998
Lawn tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
TypeLawn tractor
Original price$860 (1998 )
Craftsman 917.27031 Engine
12.5HP Briggs & Stratton 465cc 1-cyl gasoline
Fuel tank1.25 gal
4.7 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
CabOpen operator station.
Photos
No photos of the Craftsman 917.27031 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Dimensions & Tires
Front tire15x6.0-6
Rear tire18x8.5-8
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps3 (battery)
 5 (lights)
Battery CCA190
Battery volts12
Battery AH25
Battery GroupU1R
References
917.27031 reference literature
Owner's manual 917.270311 (164876) published in 1998, by Sears
