John Deere S160


John Deere S160 lawn tractor photo
2021 -
S100 Series
Lawn tractor
E160
Series:S140S160S170
Production
ManufacturerJohn Deere
TypeLawn tractor
FactoryGreeneville, Tennessee, USA
Original price$2,399 (2021 )
John Deere S160 Engine
44.2HP Briggs & Stratton 724cc 2-cyl gasoline
Fuel tank2.4 gal
9.1 L
Engine details ...
Mechanical
Chassis4x2 2WD
CabOpen operator station.
Photos
No photos of the John Deere S160 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Weight480 lbs
217 kg
Front tire15x6.00-6
Rear tire20x10.00-8
Full dimensions and tires ...
John Deere S160 attachments
48" mid-mount mower deck
snowblower
blade
Attachment details ...
S160 Serial Numbers
Location:Serial number decal above the left rear tire, below the fender deck.
Electrical
Groundnegative
Charging amps14
Battery volts12
Battery GroupU1
References
S160 reference literature
Riding Lawn Tractors published in 2021, by John Deere
Operator's Manual 100 Series Lawn Tractors (OMUC22642) published in 2020, by John Deere
