John Deere S100


John Deere S100 lawn tractor photo
2021 -
S100 Series
Lawn tractor
Series map:
S100
S110
17.5hp
19.0hp
Production
ManufacturerJohn Deere
Lawn tractor
Built in Greeneville, Tennessee, USA
Original price was $1,699 in 2021
John Deere S100 Engine
17.5HP Briggs & Stratton 499cc 1-cyl gasoline
Fuel tank2.4 gal
9.1 L
Engine details ...
Mechanical
Two-wheel drive
Open operator station.
Photos
No photos of the John Deere S100 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Dimensions & Tires
Weight415 lbs
188 kg
Front tire15x6.00-6
Rear tire20x8.00-8
Full dimensions and tires ...
John Deere S100 attachments
42" mid-mount mower deck
snowblower
blade
Attachment details ...
S100 Serial Numbers
Location:Serial number decal above the left rear tire, below the fender deck.
Electrical
Groundnegative
Charging amps8
Battery volts12
Battery GroupU1
References
S100 references literature
Riding Lawn Tractors published in 2021, by John Deere
Operator's Manual 100 Series Lawn Tractors (OMUC22642) published in 2020
Page information
Peter Easterlund - owner of TractorData.com
Copyright 2023 TractorData.com®
TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999.
Peter Easterlund - owner/author
Email: Peter@TractorData.com
Updated on May 26, 2021
