John Deere Z740R

John Deere Z740R lawn tractor photo
2019 -
Z700 Series
Zero-turn mower
Series map:
ManufacturerJohn Deere
Zero-turn mower
Built in Fuquay-Varina, North Carolina, USA
Original price was $8,549 in 2021
John Deere Z740R Engine
23.5HP Kawasaki 726cc 2-cyl gasoline
Fuel tank8 gal
30.3 L
Engine details ...
Two-wheel drive
Power steering
Two-post folding ROPS.
No photos of the John Deere Z740R are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Dimensions & Tires
Weight995 to 1040 pounds
Front tire13x6.5-6
Rear tire24x9.5-12
Full dimensions and tires ...
John Deere Z740R attachments
48" mid-mount mower deck
54" mid-mount mower deck
60" mid-mount mower deck
Attachment details ...
Battery CCA340
Battery volts12
Z740R references literature
Operator's Manual Z720E, Z730M, Z735E, Z735M and Z740R ZTrak Series Gas (OMUC23718) published in 2018
ZTrak Zero-Turn Mowers published in 2020, by John Deere
