John Deere Z535R


John Deere Z535R lawn tractor photo
2016 - 2020
Z500 Series
Zero-turn mower
Series map:
Z540M
Z535R
Z540R
24.0hp
25.0hp
24.0hp
Production
ManufacturerJohn Deere
Zero-turn mower
Built in Greeneville, Tennessee, USA
Original price was $5,399 in 2020
John Deere Z535R Engine
25HP Briggs & Stratton 724cc 2-cyl gasoline
Fuel tank4.5 gal
17.0 L
Engine details ...
Mechanical
Two-wheel drive
Power steering
Open operator station.
Photos
No photos of the John Deere Z535R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase48.7 inches
123 cm
Weight710 lbs
322 kg
Front tire13x6.5-6
Rear tire23x10.50-12
Full dimensions and tires ...
Electrical
Groundnegative
Battery CCA300
Battery volts12
References
Z535R references literature
Residential Zero-Turn-Radius ZTrak Mowers published in 2017, by John Deere
Residential Zero-Turn-Radius ZTrak Mowers published in 2017, by John Deere
Residential ZTrak Mowers published in 2018, by John Deere
