John Deere 1545


No photo available
2003 - 2004
1500 Series
Front-mount mower
Series map:
1545
1565
31.0hp
36.3hp
Production
ManufacturerJohn Deere
Front-mount mower
Built in Fuquay-Varina, North Carolina, USA
Original price was $20,849 in 2003
John Deere 1545 Engine
31HP Yanmar 1204cc 3-cyl diesel
Fuel tank14.5 gal
54.9 L
Engine details ...
Mechanical
Drive4x4 MRWD 4WD
Power steering
Wet disc brakes
Two-post folding ROPS. Four-post ROPS and cab available.
Photos
No photos of the John Deere 1545 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Dimensions & Tires
Weight1800 lbs
816 kg
Front tire26x12-12
Rear tire20x10-10
Full dimensions and tires ...
John Deere 1545 attachments
60" front-mount mower deck
72" front-mount mower deck
62" front-mount mower deck
70" front-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
1545 references literature
Operator's Manual Front Mower 1420, 1435, 1445, 1545, 1565 (OMTCU21473) published in 2002
1545 Front Mower published in 2003, by John Deere
Commercial Mowing and Portable Power Equipment published in 2003, by John Deere
Commercial Mowing and Portable Power Equipment published in 2004, by John Deere
