John Deere 1420 Series II



John Deere 1420 Series II tractor photo
2005 - 2011
1400 Series
Front-mount mower
Series map:
1420 Series II
1435 Series II
25.6hp
26.0hp
Production
ManufacturerJohn Deere
Front-mount mower
Built in Fuquay-Varina, North Carolina, USA
John Deere 1420 Series II Engine
25.6HP Yanmar 878cc 3-cyl gasoline
Fuel tank16 gal
60.6 L
Engine details ...
John Deere 1420 Series II Transmission
hydrostatic
Transmission details ...
Mechanical
Drive4x2 2WD
 4x4 MRWD 4WD
Power steering
Disc brakes
Two-post folding ROPS. Cab available with air-conditioning.
Photos
No photos of the John Deere 1420 Series II are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Dimensions & Tires
Wheelbase49.2 inches
124 cm
Front tire23x10.50-12
Rear tire18x8.50-8
Full dimensions and tires ...
John Deere 1420 Series II attachments
60" front-mount mower deck
72" front-mount mower deck
62" front-mount mower deck
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
1420 Series II references literature
1400 and 1500 Series II / 1600 Series Mowers 2004 published by John Deere
Commercial Mowing Equipment published in 2006, by John Deere
Commercial & Consumer Equipment Purchasing Guide published in 2007, by John Deere
