Craftsman 502.27021
|
|
| Production | |
| Distributor | Craftsman (a part of Sears) |
| Manufacturer | Murray |
| Riding lawn mower | |
| Craftsman 502.27021 Engine | |
| 13.5HP Tecumseh 357cc 1-cyl gasoline | |
| Fuel tank | 1 gal 3.8 L |
 Engine details ... | |
| Craftsman 502.27021 Transmission | |
| 5-speed gear | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Open operator station. |
| Photos | |
| No photos of the Craftsman 502.27021 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | manual |
| Dimensions & Tires | |
| Rear tire | 16x6.5 |
 Full dimensions and tires ... | |
| Craftsman 502.27021 attachments | |
| 30" mid-mount mower deck | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging amps | 3 |
| Battery volts | 12 |
| References | |
 | |
| A Complete Line of 2001 Riding Equipment and Attachments published by Sears |
| Page information | |
 | |
| Copyright 2026 TractorData.com® | |
| Email me: Peter@TractorData.com | |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. | |
| Peter Easterlund - owner/author | |
| This machine's data modified on November 19, 2020 |
