Ariens RM1032

Ariens RM1032 lawn tractor photo
1980 - 1989
927 Series
Riding lawn mower
Riding lawn mower
Built in Brillion, Wisconsin, USA
927007Tecumseh VM100 recoil
927008Tecumseh VM100 electric
927015Briggs 22 recoil
927016Briggs 22 electric
927023Briggs 22 electric
927026Tecumseh TVM220 recoil
927028Tecumseh TVM220 electric
Ariens RM1032 Engines
10HP Tecumseh 331cc 1-cyl gasoline
10HP Briggs & Stratton 360cc 1-cyl gasoline
10HP Tecumseh 357cc 1-cyl gasoline
Fuel tank0.75 gal
2.8 L
Engine details ...
Two-wheel drive
Manual steering
Mechanical band brakes
Open operator station.
No photos of the Ariens RM1032 are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchidler pulley
Dimensions & Tires
Wheelbase45.5 inches
115 cm
Weight390 lbs
176 kg
Front tire4.10-3.50x4
Rear tire16-6.50x8
Full dimensions and tires ...
Ariens RM1032 attachments
32" mid-mount mower deck
Attachment details ...
RM1032 references literature
Riding Mowers published in 1980, by Ariens
