Snapper LT12 Transmission


Snapper LT12 lawn tractor photo
1986 - 1988
Lawn tractor
Series map:
LT12
LT16
12.5hp
16.0hp
Transmission
Typeshaft-driven disc
Gears12 forward and 2 reverse
Snapper variable disc drive with 6 notched speed settings and two geared ranges.
Speeds
LT12  shaft-driven disc speeds
Snapper LT12 Transmission
Snapper LT12 transmission image
1Range shift
2Differential
3Axle shaft
4Drive Disc
5Driven Disc
