Craftsman 917.25157


Craftsman 917.25157 lawn tractor photo
1996
Garden tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
TypeGarden tractor
Craftsman 917.25157 Engine
25HP Kohler 624cc 2-cyl gasoline
Fuel tank3.5 gal
13.2 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
CabOpen operator station.
Photos
No photos of the Craftsman 917.25157 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Electrical
Groundnegative
Charging amps15
Battery CCA340
Battery volts12
Battery AH40
Battery GroupU1R
References
917.25157 reference literature
Craftsman Lawn and Garden Tractors published in 1996, by Sears
