Craftsman 917.25152


Craftsman 917.25152 lawn tractor photo
1996
Garden tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
Garden tractor
Variants
25151gear
25152hydrostatic
Craftsman 917.25152 Engine
20.5HP Kohler 624cc 2-cyl gasoline
Fuel tank3.5 gal
13.2 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the Craftsman 917.25152 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Electrical
Groundnegative
Charging amps15
Battery CCA280
Battery volts12
Battery AH36
Battery GroupU1R
References
917.25152 references literature
Craftsman Lawn and Garden Tractors published in 1996, by Sears
