John Deere X949


John Deere X949 lawn tractor photo
2018 -
X900 Series
Garden tractor
Series:X948X949
Production
Manufacturer:John Deere
Type:Garden tractor
Factory:Horicon, Wisconsin, USA
Variants
X940:2WD 2-wheel steer
X948:4WD 2-wheel steer
X949:4WD 4-wheel steer
John Deere X949 Engine
24.5HP Yanmar 904cc 3-cyl diesel
Engine details ...
Mechanical
Chassis:4x4 HFWD 4WD
Differential lock:mechanical rear
Steering:power four-wheel
Brakes:wet disc
Cab:Two-post folding ROPS.
Transmission:hydrostatic
Transmission details ...
Photos
No photos of the John Deere X949 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:5.2 gal
19.7 L
Hydraulics
Mid valves:2
Pump flow:5.7 gpm
21.6 lpm
Power Take-off (PTO)
Rear PTO:independent*Optional, linked with the mid PTO switch. Mechanical selector sets PTO to front, rear, or both.
Clutch:electro-hydraulic
Rear RPM:540
Mid PTO:independent
Clutch:electro-hydraulic
Mid RPM:2000
Dimensions & Tires
Wheelbase:55.7 inches
141 cm
Weight:1213 lbs
550 kg
Front tire:18x8.50-8
Rear tire:26x12.00-12
Full dimensions and tires ...
John Deere X949 attachments
48" mid-mount mower deck
54" mid-mount mower deck
60" mid-mount mower deck
Attachment details ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:40
Battery
Number:1
Cold-cranking amps:340
Volts:12
