Craftsman 502.25575
|
|
| Production | |
| Distributor | Craftsman (a part of Sears) |
| Manufacturer | Murray |
| Lawn tractor | |
| Original price was $1,599 in 1985 | |
| Craftsman 502.25575 Engine | |
| 11HP Briggs & Stratton 399cc 1-cyl gasoline | |
| Fuel tank | 1 gal 3.8 L |
 Engine details ... | |
| Craftsman 502.25575 Transmission | |
| 6-speed gear | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Open operator station. |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | manual |
| Front PTO Type | pulley |
| Dimensions & Tires | |
| Front tire | 15x6-6 |
| Rear tire | 19x9.5-8 |
 Full dimensions and tires ... | |
| Craftsman 502.25575 attachments | |
| 40" mid-mount mower deck | |
| snowblower | |
| blade | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Craftsman Tractors and Rear Engine Riders published in 1985, by Sears | |
| Craftsman Tractors and Rear Engine Riders published in 1985, by Sears | |
| Fall/Winter Catalog published in 1986, by Sears | |
| Spring/Summer Catalog published in 1986, by Sears |
