Bolens 728

No photo available
1972 - 1973
Riding lawn mower
Series map:
Riding lawn mower
Bolens 728 Engine
7HP Tecumseh 245cc 1-cyl gasoline
Fuel tank0.5 gal
1.9 L
Engine details ...
Two-wheel drive
Manual steering
Mechanical disc brakes
Open operator station.
No photos of the Bolens 728 are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Dimensions & Tires
Wheelbase43 inches
109 cm
Weight325 lbs
147 kg
Front tire4.10/3.50-4
Rear tire4.80x4.00-8
Full dimensions and tires ...
728 references literature
Riding Mower Service Manual (552568-3) published in 1980
