Craftsman 917.27062


No photo available
1998
Lawn tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
Lawn tractor
Original price was $1,380 in 1998
Craftsman 917.27062 Engine
15.5HP Briggs & Stratton 465cc 1-cyl gasoline
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Photos
No photos of the Craftsman 917.27062 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Mid PTO Typepulley
Dimensions & Tires
Front tire15x6.0-6
Rear tire18x9.5-8
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps3 (battery)
 5 (headlights)
Battery CCA190
Battery volts12
Battery AH25
Battery GroupU1R
References
917.27062 references literature
Owner's manual 917.270622 (164125) published in 1998
