Snapper 301016BE SR1030
|
|
| Production | |
| Manufacturer | Snapper |
| Riding lawn mower | |
| Snapper 301016BE Engine | |
| 10HP Briggs & Stratton 465cc 1-cyl gasoline | |
| Fuel tank | 1.75 gal 6.6 L |
 Engine details ... | |
| Snapper 301016BE Transmission | |
| 5-speed friction disc | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Drum brakes | |
| Open operator station. |
| Photos | |
 | |
 Snapper 301016BE photos... | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | manual |
| Dimensions & Tires | |
| Weight | 344 lbs 156 kg |
| Front tire | 4.10x3.50 |
| Rear tire | 16x6.50-8 |
 Full dimensions and tires ... | |
| Snapper 301016BE attachments | |
| 30" mid-mount mower deck | |
| blade | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging amps | 3 |
| Battery CCA | 140 |
| Battery volts | 12 |
| References | |
 | |
| Legendary Quality published in 1997, by Snapper | |
| Product Catalog published in 1998, by Snapper |
