Bolens 3012G ST125
|
|
| Production | |
| Manufacturer | Bolens |
| Garden tractor | |
| Built in Port Washington, Wisconsin, USA | |
| Bolens 3012G Engine | |
| 12.5HP Briggs & Stratton 655cc 2-cyl gasoline | |
| Fuel tank | 5 gal 18.9 L |
 Engine details ... | |
| Bolens 3012G Transmission | |
| 5-speed gear | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Disc brakes | |
| Open operator station. |
| Photos | |
| No photos of the Bolens 3012G are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | electric |
| Dimensions & Tires | |
| Wheelbase | 45 inches 114 cm |
| Front tire | 15x6.00-6 |
| Rear tire | 20x8.00-10 |
 Full dimensions and tires ... | |
| Bolens 3012G attachments | |
| 36" mid-mount mower deck | |
| snowblower | |
| blade | |
 Attachment details ... |
| 3012G Serial Numbers | |
| Location: | Serial number tag on the rear fender, under the tractor seat, on the left side. |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| Battery AH | 45 |
| References | |
 | |
| High Performance published in 1987, by Bolens |
