Lawn Tractors > Simplicity > 606 990332

Simplicity 606 990332



Simplicity 606 990332 lawn tractor photo
1964 - 1967
Wonder Boy Series
Riding lawn mower
Series map:
606
6.0hp
Production
ManufacturerSimplicity (a part of Allis Chalmers)
Riding lawn mower
Built in Port Washington, Wisconsin, USA
Original price was $463 in 1967
Variants
990329606 Super
990333606 Special
Simplicity 606 Engine
6HP Briggs & Stratton 231cc 1-cyl gasoline
Engine details ...
Simplicity 606 Transmission
2-speed gear
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the Simplicity 606 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Dimensions & Tires
Front tire11x4.00-5
Rear tire16x6.50-8
Full dimensions and tires ...
Simplicity 606 attachments
32" mid-mount mower deck
blade
Attachment details ...
References
606 990332 references literature
the new look of Simplicity action '67 published in 1967
