Production | |
Manufacturer | John Deere |
Lawn tractor | |
Built in Greeneville, Tennessee, USA |
John Deere X105 Engine | |
6.9KW Briggs & Stratton 344cc 1-cyl gasoline | |
Fuel tank | 2.4 gal 9.1 L |
![]() |
John Deere X105 Transmission | |
mechanical CVT | |
![]() |
Mechanical | |
Two-wheel drive | |
Manual steering | |
Open operator station. |
Photos | |
No photos of the John Deere X105 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Power Take-off (PTO) | |
Mid PTO | independent |
Clutch | mechanical |
Dimensions & Tires | |
Wheelbase | 48.3 inches 122 cm |
Weight | 412 lbs 186 kg |
Front tire | 15x6-6 |
Rear tire | 20x8-8 |
![]() |
John Deere X105 attachments | |
106 cm mid-mount mower deck | |
![]() |
Electrical | |
Ground | negative |
Battery volts | 12 |
References | |
![]() | |
The Complete Range of Lawn Care Solutions published in 2016, by John Deere |
