White FR-11 Turf Boss
|
|
| Production | |
| Manufacturer | White (a part of MTD) |
| Front-mount mower | |
| Original price was $3,700 in 1987 | |
| White FR-11 Engine | |
| 11HP Briggs & Stratton 399cc 1-cyl gasoline | |
| Fuel tank | 4 gal 15.1 L |
 Engine details ... | |
| White FR-11 Transmission | |
| hydrostatic | |
 Transmission details ... |
| Mechanical | |
| Drive | 3x2 2WD |
| Final drives | roller chain |
| Power steering | |
| Disc brakes | |
| Open operator station. | |
| Photos | |
| No photos of the White FR-11 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Front PTO | independent |
| Clutch | electro-magnetic |
| Front RPM | 3450 |
| Dimensions & Tires | |
| Wheelbase | 41 inches 104 cm |
| Weight | 500 lbs 226 kg |
| Front tire | 16x6.50-8 |
| Rear tire | 11x4.00-5 |
 Full dimensions and tires ... | |
| White FR-11 attachments | |
| 42" front-mount mower deck | |
| snowblower | |
| blade | |
 Attachment details ... |
| FR-11 Serial Numbers | |
| Location: | Model codes shown. |
| 1985 | 135-001-190 |
| 1986 | 136-001-190 |
| 1987 | 137-001-190 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| Battery AH | 32 |
| References | |
 | |
| Grounds Keeping Tractors published in 1985, by White |
