Yanmar YM126
|
|
| Production | |
| Manufacturer | Yanmar |
| Garden tractor | |
| Yanmar YM126 Engine | |
| 12HP Yanmar 534cc 1-cyl diesel | |
| Fuel tank | 2.6 gal 9.8 L |
 Engine details ... | |
| Yanmar YM126 Transmission | |
| 6-speed two-speed power shift | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Mechanical drum brakes | |
| Open operator station. |
| Photos | |
| No photos of the Yanmar YM126 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 853 psi 58.8 bar |
| Pump flow | 2 gpm 7.6 lpm |
| Tractor hitch | |
| Rear Type | 0 |
| Rear lift (at ends) | 375 lbs 170 kg |
| Rear lift (at 24"/610mm) | 276 lbs 125 kg |
| Power Take-off (PTO) | |
| Rear PTO | transmission |
| Rear PTO Type | 2000 |
| Front PTO | independent |
| Clutch | electric |
| Dimensions & Tires | |
| Wheelbase | 51.5 inches 130 cm |
| Weight | 831 lbs 376 kg |
| Front tire | 16x6.50-8 |
| Rear tire | 23x10.50-12 |
 Full dimensions and tires ... | |
| Yanmar YM126 attachments | |
| 42" mid-mount mower deck | |
| 48" mid-mount mower deck | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 15 |
| Battery volts | 12 |
| Battery AH | 47 |
| References | |
 | |
| Operation Manual YM142 - YM146 - YM122 - YM126 (OME122-146(1)-8306) published in 1983 |
